The KNAUER AZURA® MWD 2.1L is a sensitive 8-channel UV/VIS multiwavelength detector designed for analytical, semi-preparative, and preparative liquid chromatography. Combining excellent performance, user-friendly operation, and affordability, it provides a versatile solution for routine and advanced LC applications.
The detector features a newly developed optical unit and intelligent temperature management to ensure maximum sensitivity with minimal baseline drift. Optional LightGuide flow cells based on total internal reflection technology maximize light throughput and minimize peak dispersion, resulting in an optimized signal-to-noise ratio. An optional fiber-optic adapter allows physical separation of the flow cell from the detector, increasing safety when handling hazardous, explosive, or toxic materials.
The AZURA® MWD 2.1L can also be upgraded to a full AZURA® DAD 2.1L diode array detector, protecting future investments and enabling greater analytical flexibility.
Key Features
- Sensitive 8-channel UV/VIS multiwavelength detector
- Wavelength range from 190 to 700 nm
- Simultaneous monitoring of up to 8 digital channels
- LightGuide flow cell technology for improved sensitivity and signal-to-noise ratio
- Intelligent temperature management for minimal baseline drift
- Wide selection of analytical, semi-preparative, and preparative flow cells
- Optional fiber-optic adapter for remote flow cell positioning
- Internal holmium filter for wavelength verification
- Integrated leak sensor
- Front-access lamp replacement
- Upgradeable to the AZURA® DAD 2.1L diode array detector
- Compatible with ClarityChrom®, OpenLAB®, Chromeleon™, PurityChrom®, and Mobile Control
Technical Specifications
Detection System
- Detector type: Multiwavelength Detector (MWD)
- Digital channels: 8
- Analog channels: 4
- Light source: Deuterium lamp with integrated GLP chip
- Wavelength range: 190–700 nm
- Spectral resolution: <10 nm (FWHM)
- Slit width: 7.0 nm
- Wavelength accuracy: ±1 nm
- Wavelength repeatability: ±0.1 nm
Performance
- Noise: ±5 µAU at 254 nm
- Drift: 400 µAU/h at 254 nm
- Linearity: >2.0 AU at 274 nm
- Maximum data rate:
- 100 Hz via LAN
- 12.5 Hz via analog output
Flow Cells
- Flow cells sold separately
- Stainless-steel and bio-inert configurations available
- Optional LightGuide total-reflection technology
Control and Communication
- LAN (RJ-45)
- USB service interface
- Analog inputs and outputs
- Mobile Control stand-alone operation
- Full software integration with chromatography data systems
GLP Functions
- Lamp identification
- Lamp operating hours
- Lamp ignition count
- Comprehensive GLP reporting
Power and Dimensions
- Power supply: 100–240 V, 50–60 Hz
- Power consumption: 75 W
- Dimensions (W × H × D): 361 × 158 × 523 mm
- Weight: 12.2 kg
