The Organomation NITRO (NiGen Nitro 35 / 70) is a high-performance nitrogen generator based on PSA technology, designed for applications requiring flow rates up to 70 L/min and purity up to 99.99%.
It is available in two models:
- NITRO 35 – up to 35 L/min
- NITRO 70 – up to 70 L/min
The system delivers a dew point below -50 °C and hydrocarbon levels below 0.01 ppm, making it suitable for demanding applications such as LC/MS.
An integrated 24 L internal tank ensures stable nitrogen supply and reduces downtime. The unit features a touchscreen display, supports remote access via Claind4You, and enables full system integration using MODBUS, MQTT, and HTTPS protocols.
Key Features
- Two models: 35 and 70 L/min
- Nitrogen purity up to 99.99%
- Dew point < -50 °C
- Hydrocarbon content < 0.01 ppm
- PSA (Pressure Swing Adsorption) technology
- 24 L internal storage tank
- Touchscreen display with monitoring and alerts
- Remote control via Claind4You
- Integration via MODBUS, MQTT, HTTPS
- Automatic operation with leak detection
- Mobile design with wheels
- Reliable continuous operation
Available Models
NITRO 35
- Flow rate: up to 35 L/min
- Weight: 75 kg
NITRO 70
- Flow rate: up to 70 L/min
- Weight: 90 kg
Standard Features
- PSA nitrogen generator (Claind technology)
- Touchscreen display
- Automatic operation with alarms
- Alarm logging and diagnostics
- 24 L internal tank
- Remote access (Claind4You)
- Communication protocols (MODBUS, MQTT, HTTPS)
- Wheels for mobility
Technical Specifications
General
- Model: NiGen Nitro 35 / 70
- Technology: PSA
- Purity: up to 99.99%
- Dew point: < -50 °C
- Hydrocarbons: < 0.01 ppm
- Output pressure: 0–6.5 bar (0–94 psi)
Flow Rate
- NITRO 35: up to 35 L/min
- NITRO 70: up to 70 L/min
Air Input Requirements
- Particles: ≤ 0.01 µm
- Oil: ≤ 0.01 mg/m³
- Moisture: ≤ 3 °C dew point
- Air flow:
- 35: up to 90 L/min
- 70: up to 170 L/min
Electrical
- 115 / 230 V
- 50–60 Hz
- Power consumption: 200 W
Operating Conditions
- Temperature: 5–40 °C
- Humidity: 5–80%
- Max altitude: 2000 m
Dimensions
- 92 × 26.5 × 75 cm
Weight
- NITRO 35: 75 kg
- NITRO 70: 90 kg
Communication
- MODBUS (TCP), MQTT, HTTPS
- Wi-Fi connectivity
Protection
- IP20
Warranty
- 2 years
Accessories
- 100 L reservoir (air or nitrogen storage)
- Installation kit for LC/MS (A200)
- Dual Purity module (99.999% for LC-MS collision cell)
