The NITRO-GEN+ Nitrogen Generator is designed to satisfy the needs of the LC-MS and sample preparation fields. The NITRO-GEN+ is compatible with all Organomation nitrogen evaporators up to 100 sample positions, along with most LC-MS analyzers on the market. It relies on Pressure Swing Adsorption (PSA) technology to separate nitrogen from the air. The unit uses molecular sieves to remove oxygen, water, and trace hydrocarbons, leaving a stream of high purity nitrogen gas. Nitrogen is produced by utilizing a combination of this Carbon Molecular Sieve technology along with high and low pressure compressors.
This unique technology allows the nitrogen to be produced at a low pressure and an ambient temperature, eliminating the need for high pressure cylinders which can be dangerous for the technicians handling them. The low pressure also ensures a longer compressor life, which reduces the time and money spent on regular maintenance. The generator's simple installation and operation combined with its superior reliability makes the NITRO-GEN+ a staple in any laboratory.
Standard features
- Integrated low noise, oil free compressors
- On-demand supply 24/7
- Proprietary carbon molecular sieve technology
- Complete "plug and play" LC-MS solution
- Two-year complete product warranty or 8,000 hour run-time warranty
Compatible features
- All Organomation evaporators up to 100 sample positions
- Most LC-MS analyzers on the market
Specification
Key Features:
- Flow Rate: Up to 35 L/min
- Nitrogen Purity:
- Up to 99% at ≤ 25 L/min
- Up to 98% at > 25 L/min
- Dewpoint: -58 °F (-50 °C)
- Output Pressure: 0 – 116 PSI (0 – 8 bar)
- Warm-Up Time: 20 minutes
- Technology: Carbon molecular sieve (CMS)
Electrical & Safety:
- Power Supply:
- 110–120 V, 60 Hz
- 220–240 V, 50 Hz
- Total Wattage: 1800 W
- Protection Rating:
- Electrical: IP20
- Mechanical Impact: IK08
- Noise Level: 55 dBA at 1 meter
Dimensions & Weight:
- Size (W × D × H): 18.9 × 33 × 25 in (48 × 83.8 × 63.5 cm)
- Weight: 198 lbs (90 kg)
Connections & Certifications:
- Outlet Connection: 6 mm OD compression or 1/4"
- Certifications: CE, FCC, MET (UL and CSA compliant)
Environmental Specifications:
- Operating Temperature: 59–95 °F (15–35 °C)
- Relative Humidity:
- 0–80% (non-condensing)
- 0–99% (with condensation drain)
- Altitude: < 2000 m (800–1150 hPa)
Warranty: 2 years or 8,000-hour runtime (whichever comes first)
