The Agilent J&W DB-FATWAX Ultra Inert Intuvo GC column module is designed for the efficient analysis of fatty acid methyl esters (FAMEs), triglycerides, and other polar compounds. Built on the Ultra Inert platform, it provides excellent peak shape, low bleed, and enhanced sensitivity for active analytes. This Intuvo-specific module offers plug-and-play installation with no tools required.
- Agilent J&W DB-FATWAX Ultra Inert Intuvo GC Column Module
- Part Number: G3909-63002
Key Features
- Ultra Inert deactivation ensures superior performance for acidic and polar compounds
- WAX-type stationary phase for enhanced FAME and food matrix separations
- Low column bleed, ideal for sensitive MS detection
- Optimized for speed and robustness in complex sample analysis
- Intuvo click-and-run module design simplifies column changes
Specifications
- Length: 20 meters
- Inner Diameter: 0.18 mm
- Film Thickness: 0.18 µm
- Stationary Phase: Polyethylene glycol (PEG) – WAX-type
- Polarity: Polar
- Maximum Temperature: Typically up to 260 °C (depending on method)
- Recommended Use: FAMEs, oils, fats, food testing, environmental samples
- Instrument Compatibility: Agilent Intuvo 9000 GC only
