The Genius NM32LA from Peak Scientific is a proven and highly trusted nitrogen generator, specifically developed to meet the demands of LC-MS applications. With a production history spanning over a decade, the NM32LA stands as the flagship model in Peak’s Genius series — a reliable on-demand gas solution now found in thousands of laboratories worldwide.
Using tried and tested membrane separation technology and integrated internal compressors, the NM32LA generates laboratory-grade nitrogen on-site and on demand, eliminating the dependency on high-pressure gas cylinders. Designed for long-term operation with minimal maintenance, the unit is compact enough to fit under a standard lab bench and comes equipped with wheels for easy mobility.
The NM32LA is plug-and-play: once connected to power and the instrument, it becomes fully operational. Its high-spec compressor is housed in an insulated chamber to reduce noise and vibration, offering a quiet and efficient solution for gas supply. Peak Scientific also provides robust aftercare and service plans to ensure consistent uptime and performance.
Key Features
- Compressor-based, standalone operation (no external air source required)
- Fully operational upon connection to power and instrument
- Compatible with the majority of LC-MS instruments
- Duty and service indicators for user-friendly maintenance planning
- Low-noise, insulated compressor chamber
- Eliminates the hassle and safety risks of gas cylinders
- Cost-effective and reliable long-term gas supply
- Dual tap transformer available for 110V labs
Technical Specifications
- Max Flow Rate: 32 L/min
- Max Pressure: 100 psi / 6.9 bar
- Max Relative Humidity: 80% Non-Condensing
- Max Altitude: 2000 Metres
- Particles: < 0.01μm
- Gas Outlets: 1x 1/4” BSP Female
- Phthalates: None
- Suspended Liquids: None
- Operating Temperature: 5ºC - 35ºC / 41ºF - 95ºF
- Electrical Requirements: 230v 50/60Hz 7.0A
- Power Consumption: 1610 Watts
- Noise Level: 59 dB
- Generator Dimensions (HxWxD): 713 x 600 x 750 mm/28.1 x 23.6 x 29.5 in
- Generator Weight: 102.5 Kg (226 lbs)
