The Shimadzu Preparative HPLC System is engineered to separate and purify high-purity target compounds from complex mixtures. This system is indispensable for synthesizing reactions, natural extracts, and large-scale purification tasks. It features automated purification processes, customizable hardware configurations, and a flexible design.
This configuration includes:
- Shimadzu LC-20AP Preparative pump (2x)
- Shimadzu SIL-10AP Preparative Autosampler
- Shimadzu FRC-10A Fraction Collector
- Shimadzu SPD-20A UV-Vis Detector
- Shimadzu CBM-20A System Controller
💡 Need another configuration? We are happy to provide the configuration you need for your application, individual modules or spare parts. Send us an inquiry.
Key Features:
- High-Performance Pumping Systems
The system offers precise gradient and flow rate control to achieve accurate separation and high reproducibility in preparative applications. - Automated Fraction Collection
Supports various collection modes and configurations for optimal fraction recovery and reduced sample loss, allowing efficient processing of complex samples. - Scalable Column Compatibility
Accommodates a wide range of column sizes, from analytical to preparative columns, offering flexibility across research, process development, and production applications. - Intuitive Software Interface
Shimadzu’s LabSolutions software provides a user-friendly interface for data management, method development, and real-time monitoring. - Robust System Control & Diagnostics
Integrated system monitoring and diagnostic tools ensure stable and consistent performance with minimal downtime.
Technical Specifications:
LC-20AP Preparative pump
- Flow Rate: 0.01 to 150.0 mL/min
- Maximum Pressure: 42.0 MPa
- Plunger Capacity: 250 µL
- Gradient Type: Constant-Pressure Solvent Delivery
- Flow Rate Accuracy: No more than ±1% (1 mL/min, 10 MPa)
- Operating Temperature Range: 4 to 35°C
- Size and Weight: 260 x 210 x 500 mm, 19 kg
SIL-10AP Preparative Autosampler
- Injection Method: Loop injection with variable injection volume
- Injection Volume Range: 1 µL to 5,000 µL (standard)
- Injection Volume Precision: Relative standard deviation (RSD) ≤ 1% at 10 µL injection
- Sample Capacity:
- 100 × 1.5 mL vials (60 with optional cooler)
- 80 × 4 mL vials (50 with optional cooler)
- 25 × 13 mL vials
- 192 samples with two 96-well microtiter plates
- Needle Rinsing: Programmable pre- and post-injection
- Sample Cooler: Optional cooling unit (4 °C to 70 °C)
- Operating Temperature: 4 °C to 35 °C
- Operating pH Range: pH 1 to pH 10
- Dimensions: 260 (W) × 280 (H) × 420 (D) mm
- Weight: 19 kg (main unit)
FRC-10A Fraction Collector
- Capacity: 144 × 5 mL vials (expandable)
- Temperature: 4 °C to 70 °C (Peltier-controlled)
- Collection Modes: Volume, threshold, and peak purity
- Control: Graphical setup via SCL-10AVP Controller
- Adaptability: Auto-adjusts for retention shifts, with slope-override feature
FRC-10A Fraction Collector
- Capacity: 144 × 5 mL vials (expandable)
- Temperature: 4 °C to 70 °C (Peltier-controlled)
- Collection Modes: Volume, threshold, and peak purity
- Control: Graphical setup via SCL-10AVP Controller
- Adaptability: Auto-adjusts for retention shifts, with slope-override feature
SPD-20A UV-Vis Detector
- Light Source: Deuterium lamp (SPD-20A); Deuterium + tungsten (SPD-20AV)
- Wavelength: 190-700 nm (SPD-20A); 190-900 nm (SPD-20AV)
- Accuracy: ±1 nm; Precision: ±0.1 nm
- Noise: 0.5 × 10⁻⁵ AU; Drift: 1 × 10⁻⁴ AU/h
- Linearity: Up to 2.5 AU
- Flow Cell: 10 mm path, 12 µL volume, 12 MPa
- Dimensions: 260 × 140 × 420 mm; Weight: 13 kg
CBM-20A System Controller
- Connection: Controls up to 8 modules (expandable to 12); connects via Ethernet
- Data Buffering: 24 hours (500 ms sampling rate, with LCsolution)
- Web Control: Remote setup, control, and monitoring via web browser
- Event I/O: 4 inputs, 4 outputs
- Analog Input: Supports up to 2 analog boards
- Auto-Purge: Automates purge for pumps and autosamplers
- Dimensions & Weight: 260 (W) × 140 (H) × 420 (D) mm; 5.5 kg
- Power: 100 VAC, 100 VA, 50/60 Hz
Why Choose Refurbished?
Purchasing a refurbished items from LabRulez provides exceptional value without compromising on quality. Our refurbishment process includes:
- Thorough Inspection and Testing: Each unit undergoes rigorous testing to ensure it meets original performance specifications.
- Updated Components: All critically worn or malfunctioning components and materials are replaced with new ones to extend the life and reliability of the modules after installation and to meet all manufacturer's performance requirements.
- Cost Efficiency: Save up to 70% of the cost compared to buying a new module or part, freeing up budget for other important lab expenses.
Why Buy from LabRulez?
LabRulez is committed to providing high-quality, reliable laboratory equipment at competitive prices. With our extensive experience in refurbishing and reselling scientific instruments, we guarantee:
- Expert Support: Our fully trained and experienced team of specialists is available to assist with installation, operation, and troubleshooting.
- Flexible Payment Options: Choose from a range of payment methods that suit your procurement process.
- Fast and Secure Shipping: Get your equipment delivered quickly and safely to your lab.
